batareya quvvatini saqlash tizimi

solar power batteries

Benwei konteyner batareyasi

batareya quvvatini saqlash tizimi

Konteynerli energiya saqlash tizimimiz (BESS) yirik-miqyosdagi energiya saqlash loyihalari uchun mukammal yechimdir.

Energiya saqlash idishlari turli xil saqlash texnologiyalarini birlashtirishda va turli maqsadlarda ishlatilishi mumkin.

Mahsulot spetsifikatsiyasi:

Model	BW 220100	BW 220200	BW 360100	BW 360200	BW 384100	BW 384200
Yadro turi	Lityum temir fosfat
Nominal energiya (KWH)	22	44	36	72	40	80
Nominal quvvat (AH)	100	200	100	200	100	200
Nominal kuchlanish (VDC)	220.8			358.4	384
Ishlash kuchlanish diapazoni (VDC)	179259		291420		312450
Tavsiya etilgan zaryadlash kuchlanishi (VDC)	242		392		420
Tavsiya etilgan tushirish kuchlanishi (VDC)	210		342		366
Standart zaryadlash oqimi (A)	50	80	50	80	50	80
Maksimal uzluksiz zaryad oqimi (A)	100	200	100	200	100	200
Standart tushirish oqimi (A)	50	80	50	80	50	80
Maksimal uzluksiz tushirish oqimi (A)	100	200	100	200	100	200
Ishlash harorati	-2065 daraja
Himoya darajasi	IP20
Aloqa interfeysi	RS485/CAN ikkitasi bittasini tanlaydi
Malumot og'irligi (kg)	300	600	470	940	500	1000
Malumot hajmi (DWHmm)	5306501180	6255501810	5305501810	(6255502040)2	5305502020	(6255501600)2

Batafsil:

solar energy storage batteries

solar backup battery

lithium battery storage container

solar energy battery

20kw solar system with battery storage

solar power storage systems

Photovoltaic Utility Scale Lithium Battery Storage

Cautions:

● The charging current should be less than the maximum charging current specified in the product specifications. A charging current greater than the recommended current may damage the battery;

● The discharge current should be less than the maximum discharge current specified in the product specifications; the discharge current greater than the recommended current may damage the battery;
● Do not reverse the polarity of the battery pack for any reason;
● Do not charge in reverse polarity;
● Please use a professional charger for charging;
● If the lithium battery is not used for a long time, it should be charged with 50 percent 80 percent power, stored separately in a dry and cool environment, and recharge the battery every 3 months to avoid long storage time and low power due to self-discharge of the battery, Will cause the battery performance,characteristics or battery function to decline;
● A single battery cell is not waterproof, and the finished battery pack has a waterproof layer to prevent rain. But do not soak in water and do not expose the battery to a high-temperature open flame.
● If you want to DIY yourself, please ensure that the battery voltage is the same when installing the battery. Be careful not to short-circuit the battery. There are more protection boards, batteries, and finished battery packs on sale in the store. You can view more.
